NASA’s next generation of deep space exploration missions may require spacecraft to refuel in Earth orbit before pushing farther into the solar system. For this purpose, a special device known as a cryocoupler is being developed to enable spacecraft to connect to future orbital propellant depots. Cryogenic fluid management is a vital technology for these missions, as it involves the transfer of cryogenic, or super-cold, fluids without losing propellant or performance.
Cryogenic propellants like liquid hydrogen and liquid oxygen must stay chilled to hundreds of degrees below zero Fahrenheit, placing strict demands on the materials, seals, and mechanisms that move them. The challenge of reliably transferring these fluids is significant, and NASA is working to overcome it. In-orbit cryogenic refueling between two spacecraft has yet to be done and remains one of the toughest engineering challenges in spaceflight.
Cryogenic Fluid Management Challenges
Ground-based couplers like those used to fill the SLS for Artemis missions are not an option for orbiting propellant transfers. Those couplers release quickly while a rocket is launching and must be manually reconnected for the next flight. They also are not designed to operate in the harsh environment of space and are much larger than what would be used to refill an orbiting spacecraft’s fuel tank.
To meet these challenges, NASA tested a cryocoupler developed by L3Harris. The cryocouplers being worked on can attach and detach multiple times and are fully automated, so astronauts won’t have to perform a spacewalk to transfer propellant. They’re rigorously designed to withstand space and sized for the expected tank designs.
Cryocoupler Testing
A joint NASA and L3Harris team recently conducted two types of tests at NASA Marshall. To ensure the cryocoupler can handle the extremely cold temperatures it will be exposed to, they ran liquid nitrogen at minus 321 degrees Fahrenheit through multiple connected and disconnected configurations to observe how the coupler reacts to thermal contraction, flow, and significant temperature differences between propellant and materials.
The team also put the cryocoupler through operational tests to determine its performance limits. In this setup, one coupler half was mounted to a robotic table that could move and rotate in any direction, allowing it to simulate misaligned docking with the other half, which remained stationary above the table.
- Cryogenic fluid management is a critical step toward making in-orbit refueling a reality.
- The development of cryocouplers is essential for future space missions.
- NASA’s testing of the cryocoupler is a significant milestone in the development of this technology.
Implications and Future Developments
The successful development of cryogenic fluid management technology will have significant implications for future space missions. It will enable spacecraft to refuel in orbit, extending their mission duration and capabilities. The technology will also have applications in other areas, such as satellite servicing and space-based manufacturing.
As NASA continues to develop and test cryogenic fluid management technology, several questions remain to be answered. What are the long-term effects of cryogenic fluid exposure on spacecraft materials and systems? How will the technology be integrated into future spacecraft designs? What are the potential risks and challenges associated with in-orbit refueling, and how will they be mitigated?
Conclusion
NASA’s cryogenic fluid management program is a critical step toward enabling future space missions. The development of cryocouplers and other related technologies will play a vital role in making in-orbit refueling a reality. As the program continues to advance, it is likely to have significant implications for the future of space exploration.
Source: nasa.gov.
